Patch capacitance breakdown table



Material COG NPO X7R X5R Y5V



Temperature range-55+125-55+125-55+125-85-30+85 Capacity range 1-10p1-100p100p-100nf letters G JKMZ above.



Error +2%+5%+10%+20%+80%-20%





Series parameters of SMD capacitor products
Volume: 0201, 0402, 0603, 0805, 1206, 1210, 1808, 1812, 1825, 2220 and 2225.

Voltage: 6.3V, 10V, 16V, 25V, 50V, 100V, 250kv, 500V, 630V, 1kv, 2kv, 3kv, 5kV;

Packing: 0402:10000/ tray 0603 4000/ tray 0805 1206 1044000/ tray over 105 2000/ tray



Patch capacitor characteristics:

1. The product has high dimensional accuracy and is convenient for efficient assembly of automatic mounter;
2. The terminal electrode is a three-layer electrode, which is suitable for wave soldering and reflow soldering;
3. The dielectric body and the outer surface are made of the same material, which has little influence from environmental conditions, high insulation resistance and high reliability;
4. It contains various temperature characteristic media from COG to Y5V, and is suitable for precision instruments, telecommunication instruments, electronic equipment and other common electronic equipment.



PAGOODA is a supplier of integrated SMD electronic components in the world of laminated ceramic technology. The high-voltage ceramic capacitor 0805 105kX7R 1UF 16V25V50V+10% is one of the MLCC products of SMD capacitor.
